Multiple automatic protection, comprehensive fault self-diagnosis;
* Precise craftsmanship and high-quality international brand components ensure the product is more stable and reliable;
* Suitable for T3 high-temperature conditions and R134a environmentally friendly refrigerant;
* Standard RS485 interface for remote measurement, remote signaling, and remote adjustment;
* LED digital display, on-site parameters can be set;
* Dry contact alarm output, with options for normally open or normally closed;
|
型号/Model
|
HDC 030 /025DS
|
HDC050/020DS
|
|
电源/Power Supply
|
-48VDC
|
-48VDC
|
|
制冷量/Cooling Capacity
|
3000W @L35/L35
|
5000W@L35/L35
|
|
功耗/Power Consumption
|
1250W @L35/L35
|
1600W @L35/L35
|
|
换热量/Heat Exchange Capacity
|
200W/K
|
200W/K
|
|
换热功耗/Heat Exchange Consumption
|
200W
|
300W
|
|
内循环风量/Internal Airflow
|
850m³/h
|
1100m³/h
|
|
制冷运行温度范围/Cooling Working
Temperature Range
|
-15℃~+55℃
|
-40℃~+55℃
|
|
安装方式/Mounting Method 外形尺寸/Dimensions (mm,H*W*D)
|
半嵌入/ Semi-embedded Mounting 1350x550x350
|
半嵌入/ Semi-embedded Mounting
1550x650x438
|
|
IP等级/IP Grade
|
IP55
|
IP55
|
|
制冷剂/Refrigerant
|
R134a
|
R134a
|
|
净重/Net Weight
|
79kg
|
100kg
|
|
表面处理/Surface Treatment
|
RAL7035
|
RAL7035
|
