Product Description
Integrated design, reducing on-site installation and commissioning costs;
· Full variable frequency design, highly energy-efficient;
· Wide voltage adaptability, allowing voltage fluctuations of ±20%;
· Standard RS485 communication interface, optional CAN communication;
· Has power-on self-starting function, and provides multiple alarm and protection functions;
· Small size, compact structure, protection grade IPX5;
· PTC heating, meeting the heating requirements of equipment in low-temperature scenarios;
· Can operate continuously for 24 hours, with a design service life of over 10 years;
· Operating temperature range: -30℃ to 55℃;
· Optional silent version configuration, noise as low as 65db.
|
型号/Model
|
LCS0030W
|
LCS0060W
|
LCS0080W
|
LCS0100W
|
LCS0030W（静音版）
|
LCS0060W（静音版）
|
|
Refrigeration capacity
|
KW
|
3
|
6
|
8
|
10
|
3
|
6
|
|
Power consumption（35℃）
|
kW
|
1.15
|
2.4
|
3.2
|
4.16
|
1.2
|
2.14
|
|
EER (35°C)
|
/
|
2.6
|
2.5
|
2.5
|
2.4
|
2.5
|
2.8
|
|
Power consumption（45℃）
|
kW
|
1.5
|
3.15
|
4.21
|
5.26
|
1.5
|
3
|
|
EER (45°C)
|
/
|
2
|
1.9
|
1.9
|
1.9
|
2
|
2
|
|
Rated outlet water temperature
|
℃
|
18
|
18
|
18
|
18
|
18
|
18
|
|
Electric heating
|
kW
|
2
|
2
|
2
|
2
|
2
|
2
|
|
Receiving pipe diameter Traffic
|
/
|
NW26
|
NW26
|
NW26
|
NW26
|
NW26
|
NW26
|
|
Traffic
|
L/min
|
30
|
50
|
60
|
90
|
40
|
50
|
|
扬程
|
kPa
|
80
|
80
|
80
|
90
|
90
|
90
|
|
Refrigerant
|
/
|
R410A
|
R410A
|
R410A
|
R410A
|
R410A
|
R410A
|
|
Size
|
Wide
|
mm
|
700
|
700
|
780
|
810
|
700
|
800
|
|
深
|
mm
|
900
|
900
|
1050
|
1100
|
900
|
1100
|
|
High
|
mm
|
245
|
245
|
290
|
450
|
245
|
300
|
|
Unit weight
|
kg
|
70
|
75
|
110
|
130
|
75
|
100
|
|
Power supply
|
V/Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
380V/50Hz
|
220V/50Hz
|
220V/50Hz
|
|
Operating temperature range
|
℃
|
-30～55
|
-30～55
|
-30～55
|
-30～55
|
-30～55
|
-30～55
|
|
External circulation air outlet mode
|
Move forward and exit backward
|
Move forward and exit backward
|
Move forward and exit backward
|
Move forward and exit backward
|
Move forward and exit backward
|
Move forward and exit backward
|
|
Installation method
|
Embedded horizontal style
|
Embedded horizontal style
|
Embedded horizontal style
|
Embedded horizontal style
|
Embedded horizontal style
|
Embedded horizontal style
|
