Working principle:
When humid air is sucked in by the fan, it flows through a specially designed duct and is first cooled by a semiconductor cooler. Condensation occurs, and the condensed water drops into the water collection tank under the influence of gravity. Then, it flows out of the cabinet through the water pipe. Within the set startup value, the dehumidification process is fully carried out, reducing the cabinet's air humidity below the condensation point, completing the entire moisture-proof, condensation prevention, and heating process. At the same time, the signal collection sensor of the semiconductor dehumidification device is external, and it can accurately and real-time collect the actual humidity inside the cabinet, ensuring that the dehumidification device starts in advance when the cabinet is about to reach the condensation condition.
|
型号/Model
|
HD 1L004
|
|
安装方式/Mounting Method
|
壁挂/Wall Mount
|
|
电源/Power Supply
|
220VAC
|
|
除湿量/Dehumidification capacity
|
1L/D (35℃ 85 RH)
|
|
功耗/Power Consumption
|
120W
|
|
工作温度/Work Temperature
|
5℃~55℃
|
|
净重/Net Weight
|
2.6Kg
|
|
外形尺寸/Dimensions
|
126X70X305(mm,HxWxD)
|
|
通讯方式/Communication method
|
可选配RS485
|
