High-efficiency Rotor DC Frequency-Variable Compressor and Fan: Reliable and energy-saving;
* Intelligent Communication: RS485 communication port and dry contact alarm output port, facilitating remote monitoring;
* Digital Display: On-site parameters can be set, and the internal operation status can be displayed;
* High Protection Grade: Perfectly applicable for outdoor use;
* Easy Maintenance Design: Reduces maintenance difficulty;
* Wide Operating Temperature Range: Reliable operation under all environmental conditions;
* Heating Function Optional
|
型号/Model
|
HDC003DS
|
HDC005DS
|
HDC010DS
|
HDC015DS
|
HDC020DS
|
|
电源/Power Supply
|
-48VDC(-DC44 -59V)
|
-48VDC(-DC44 -59V)
|
-48VDC(-DC44 -59V)
|
-48VDC(-DC44 -59V)
|
-48VDC(-DC44 -59V)
|
|
制冷量/Cooling Capacity
|
300W @L35/L35
|
500W @L35/L35
|
1000W @L35/L35
|
1500W @L35/L35
|
2000W @L35/L35
|
|
功耗/Power Consumption
|
120W@L35/L35
|
180W @L35/L35
|
295W @L35/L35
|
495W @L35/L35
|
710W @L35/L35
|
|
安装方式/Mounting Method 外形尺寸/Dimensions(mm,H*W*D)
|
半嵌入 /Semi-embedded Mounting 380x219x133(含法兰)
|
半嵌入 /Semi-embedded Mounting 583x352x175(含法兰)
|
半嵌入 /Semi-embedded Mounting 783x483x200(含法兰)
|
半嵌入 /Semi-embedded Mounting 783x483x200(含法兰)
|
半嵌入 /Semi-embedded Mounting 783x483x200(含法兰)
|
|
IP等级/IP Grade
|
IP55
|
IP55
|
IP55
|
IP55
|
IP55
|
|
制冷剂/Refrigerant
|
R134a
|
R134a
|
R134a
|
R134a
|
R134a
|
|
净重/Net Weight
|
7.5kg
|
14kg
|
28kg
|
29kg
|
33kg
|
|
表面处理/Surface Treatment
|
RAL7035
|
RAL7035
|
RAL7035
|
RAL7035
|
RAL7035
|
